| Sensor | 1/1.8″, 4.0 megapixel, progressive scan, CMOS |
| Lens | [email protected], AF automatic focusing and motorized zoom lens |
| Iris | Auto aperture |
| DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | Identify (m) |
| 2.8 | 42(137.8ft) | 16.8(55.1ft) | 8.4(27.6ft) | 4.2(13.8ft) |
| 12 | 180(590.4ft) | 72(236.2ft) | 36(118.1ft) | 18(59.0ft) |
| Angle of View (H) | 35.6°~107.9° |
| Angle of View (V) | 20.4°~75.4° |
| Angle of View (O) | 43.8°~140.3° |
| Shutter | Auto/Manual, 1 ~ 1/100000s |
| Min. Illumination | Colour:0.0005lux (F1.2, AGC ON)
0 lux with IR |
| WDR | 120dB |
| Day/Night | IR-cut filter with auto switch (ICR) |
| S/N | >55dB |
| IR Range | Up to 50m (164 ft) IR range |
| Wavelength | 850nm |
| IR On/Off Control | Auto/Manual |
| Defog | Digital Defog |
| Video |
| Video Compression | Ultra 265,H.265,H.264,MJPEG |
| Frame Rate | Main Stream: 4MP(2688*1520),Max 30fps; 4MP(2560*1440),Max 30fps; 2MP(1920*1080),Max 60fps
Sub Stream: 2MP (1920*1080), Max 60fps;
Third Stream: D1 (720*576), Max 60fps
Fourth Stream: D1 (720*576), Max 60fps
Fifth Stream: D1 (720*576), Max 60fps |
| Video Bit Rate | 128 Kbps~16 Mbps |
| ROI | Supported |
| Video stream | Five streams |
| OSD | Up to 8 OSDs |
| Privacy Mask | Up to 8 areas (8 blacks / 8 mosaics) |
| Image |
| White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Digital noise reduction | 2D/3D DNR |
| Smart IR | Support |
| Flip | Normal/Flip Vertical/Flip Horizontal/180°/90°Clockwise/90°Anti-clockwise |
| HLC | Support |
| BLC | Support |
| Smart |
| General Function | Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication |
| Audio |
| Audio Compression | G.711U,G.711A |
| Two way audio | Supported |
| Sampling Rate | 8KHZ |
| Storage |
| Edge Storage | Micro SD, up to 256 GB |
| Network Storage | ANR,NAS(NFS) |
| Network |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP |
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API |
| Client | EZStation
Ezview
EZLive |
| Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below |
| Interface |
| Audio I/O | Audio cable |
| 1 Input: impedance 35kΩ; amplitude 2V [p-p] |
| 1 output: impedance 600Ω; amplitude 2V [p-p] |
| Alarm I/O | 2/1 |
| Network | 1 x RJ45 10M/100M Base-TX Ethernet |
| Serial Port | 1 RS485 |
| Certifications |
| Certifications | CE: EN 60950-1
UL: UL60950-1
FCC: FCC Part 15 |
| General |
|
Power
| AC24V±25%, DC12V(-10%~+25%), PoE(IEEE802.3at) |
| Power consumption: Max 13.3W |
| Support overcurrent protection , Input short circuit protection |
| Dimensions (Ø x H) | Φ306.4×104.1×98.1mm(Φ12.1’’x4.1’’x3.9’’) |
| Net Weight | 1.65kg(3.64lb） |
| Material | Metal |
| Working Environment | -30℃~60℃(-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Storage Environment | -40℃~70℃(-40°F ~ 158°F), Humidity: ≤95% RH (non-condensing) |
| Surge protection | 6KV |
| Vandal Resistant | IK10 |
| Ingress Protection | IP67 |
